Also

• Survives a card that vanishes, even mid-frame. A card that loses power without warning is noticed within about a tenth of a second, and the desktop carries on. Programs drawing on it are rebuilt on the other GPU. zssctl on brings the card back without a reboot: if its driver was frozen in time it resumes, and if the driver saw the loss the card is taken off the bus and found again, the way NVIDIA's driver handles an unplugged eGPU.
• Rebuilds programs after a loss. Programs under ZSS_AirLock whose GPU disappears are rebuilt from memory on another GPU, or parked until one is available.
• Follows the charger. Unplug it and the card switches off with its programs moved; plug it back in and they return.
• Idle timer. An unused card can be switched off after a set time and comes back when something asks for it.
• Hides a switched-off card from programs started meanwhile, as if it had been unplugged, so that nothing new wakes it.
• Freezes what it can't move. A program that uses the card but wasn't started under ZSS is paused while the card is off and resumed afterwards. The report names it.
• Tester kit. A report of what any machine has for ZSS, with the moving tests, ready to email.

What it doesn't do

• It doesn't start or configure virtual machines. It prepares the host side, and any passthrough setup works after that.
• It never edits your bootloader configuration. Switching the IOMMU on, if you want lending, is your step.
• It can't move a program that wasn't started under ZSS_AirLock. Such a program is frozen, or it blocks the operation.
• After a card lost mid-frame comes back, the programs that were moved off it stay on the other GPU until you restart them, programs that present through NVIDIA's own driver (not through ZSS_AirLock) need a reboot, and the card can't be switched off or lent again until the machine restarts. See When a card is lost unexpectedly.

In one line

curl -fsSLO https://github.com/z3r0n3br4instorm/ZrnSelectiveSuspend/releases/latest/download/zss-installer.run && sh zss-installer.run

This downloads the latest release's installer into the current folder and runs it. The installer is a shell script with a compressed archive attached. Run, it does four things:

1. Unpacks itself into a temporary folder and asks for your password (through sudo).
2. Installs the daemon, the control tool and the launcher, creates the zss group and adds you to it, and sets up the zssd service.
3. If your GPU driver is one the patch has been validated against, offers to patch it. Then it offers ZSS_Interceptor, the kernel module. Both go through DKMS, so they survive kernel updates.
4. Records what your machine has for ZSS, together with its own log, in ~/.zss/debug.log. If something failed, it also saves a full report and offers to open your mail program to send it.

Arguments after sh zss-installer.run go to the installer, for example sh zss-installer.run --vm-passthrough. Log in again afterwards so your new group membership takes effect.

Look before you install

sh zss-installer.run --check

This says what the machine supports and changes nothing. It covers the GPUs and their drivers, which power backend would be used, whether the driver patch applies, the kernel module, and (for lending) whether the IOMMU is on and whether the card shares its isolation group with other devices.

Installer options

What gets installed

If no GPU could be detected for /etc/zss/zssd.conf, the installer says so: set gpu = there and run sudo systemctl enable --now zssd.

After installing

zssctl status                  # the managed GPU, its state, wake support, who is using it
zss-run vkcube                 # a program on the dedicated GPU, under ZSS_AirLock
zssctl off 0000:01:00.0        # move it away and switch the card off
zssctl on 0000:01:00.0         # switch it on and bring the program back

Find your card's address with lspci -D | grep -i -E 'vga|3d'.

The tester kit

curl -fsSLO https://github.com/z3r0n3br4instorm/ZrnSelectiveSuspend/releases/latest/download/zss-tester.run && sh zss-tester.run

It changes nothing and installs nothing. See Helping test it.

Releases

Every push to the main branch builds, tests and publishes a release on GitHub with two downloads: zss-installer-VERSION.run and zss-tester-VERSION.run. zss-installer.run and zss-tester.run are the same files under names that never change, which is what the one-liners use. Versions are MAJOR.MINOR.PATCH; the patch number counts up with each release.

Both files are built on Ubuntu 22.04 and tested on Arch Linux, and need glibc 2.34 or later. Install, --check, uninstall and the tester kit were tried on Debian 12, Ubuntu 22.04 and 24.04, Fedora 44 and openSUSE Tumbleweed. On an older system, build from source.

Removing it

sh zss-installer.run --unpack-only ~/zss-installer
sudo ~/zss-installer/packaging/uninstall.sh            # --purge also drops the settings and the group
zss-nvidia-patch remove                                # if you patched the driver: puts the stock driver back

From a source checkout, sudo ./packaging/uninstall.sh. On Arch, packaging/arch/ builds a package instead, which pacman then removes.

The parts that move programs are vendor-neutral and work with any Vulkan driver. The parts that cut power are tied to hardware: today, power-off under a running desktop needs an Apple laptop with a classic gmux and the patched NVIDIA 470 driver. On other machines the installer says so and installs program migration only.

What it would take to cover more

• amdgpu, i915/xe, nouveau. ZSS_Interceptor already runs any driver's own sleep and wake code, which also re-runs the card's video BIOS when power returns. What's missing is a trial on real hardware for each driver.
• Another laptop. The acpi backend should cover most of them and needs someone with such a machine to try it. Other platforms need a backend of their own: three functions (probe, power off, power on).
• Other NVIDIA versions. The patch has to be checked against each one and added to patches/validated-versions.

The quickest way to help is the tester kit: its report says exactly which of these rows your machine falls under.

ZSS_AirLock is a Vulkan driver that sits in front of the real ones. A program has to be started under it to be movable. zss-run does that, and starts the program on the dedicated GPU.

zss-run vkcube                     # a Vulkan program, on the dedicated GPU
zss-run --gl glxgears              # an OpenGL program, through Zink
zss-run --on 0000:00:02.0 vkcube   # start on another GPU (a PCI address, part of a name, or "any")
zss-run chromium                   # Chromium and Electron apps get their Vulkan switches automatically
zss-run --print code .             # show what would run, run nothing

Vulkan programs

Programs see a Vulkan 1.1 device, with the extensions ZSS_AirLock can carry across a move. Programs that need Vulkan 1.2 or later don't start under it yet; run those without zss-run.

What a program is offered is what every GPU it may move to has, so that nothing it turns on can hold it to one card. On the reference laptop that withholds seven features of the NVIDIA card. ZSS_PROFILE=native offers each GPU's own features instead; a program that uses the difference is then parked rather than moved.

OpenGL programs

zss-run --gl runs the program on Mesa's Zink, which draws OpenGL through Vulkan. The program is then under ZSS_AirLock like any Vulkan program and can be moved. On the reference laptop's two GPUs that gives OpenGL 3.2 and OpenGL ES 3.1.

Zink needs two things the NVIDIA 470 driver lacks: dynamic rendering and VK_KHR_maintenance5. ZSS_AirLock provides both itself on such a driver.

Browsers and Electron apps

zss-run recognises a program built on Chromium by the runtime files beside its binary, following launcher scripts to find it. It then adds two switches:

• --use-angle=vulkan makes ANGLE, which gives Chromium its OpenGL ES, draw through Vulkan.
• --enable-features=Vulkan makes Chromium's compositor draw and present through Vulkan as well.

Without them, Chromium draws through OpenGL, creates no Vulkan device, and isn't movable. --plain leaves the arguments alone. Recognised on the reference laptop: chromium, helium-browser, code (VS Code) and teams-for-linux. Chromium was moved between the NVIDIA and Intel GPUs while drawing, and kept the same GPU process throughout.

Games

• Unity games use OpenGL on Linux unless told otherwise. Start them with zss-run ./Game.x86_64 -force-vulkan, or under OpenGL with zss-run --gl ./Game.x86_64. IFSCL runs and moves under both renderers.
• Steam: in the game's Properties → Launch options, write zss-run %command% for a Vulkan game or zss-run --gl %command% for an OpenGL one. A game that Steam runs inside its runtime container may not see ZSS_AirLock; if ZSS_DEBUG=1 prints nothing, start the game's own binary with zss-run instead.
• Proton and DXVK need Vulkan 1.3, which ZSS_AirLock doesn't offer yet.
• Memory. A program can only move to a GPU with room for it. A game that fills the NVIDIA card's memory can fail to move to the Intel GPU, which has about 1.5 GB to share.

Everything you start, without typing zss-run

ZrnLaunchRouter is a separate, optional project. A small library, preloaded into the desktop session, looks at every program as it starts, whether from the menu, the runner, the dock, the file manager or a terminal. It gives it what zss-run would give it:

zrn-launch-router on                     # from the next login
zrn-launch-router check helium-browser   # what it would do with a program
zrn-launch-router log                    # what was routed, and why
zrn-launch-router off

Chromium's helper processes, and anything already under ZSS, are left alone. If ZSS isn't installed, or anything is in doubt, the program starts exactly as asked.

zssctl status                 # state, wake support, who is using the GPU
zssctl off 0000:01:00.0       # move programs away, suspend the driver, cut power
zssctl on 0000:01:00.0        # power on and bring the programs back
zssctl on 0000:01:00.0 --stay # power on, leave the programs where they are

Each step is printed as it happens:

[ZrnSelectiveSuspend] Suspending device: 0000:01:00.0  NVIDIA Corporation GK107M [GeForce GT 650M Mac Edition]
[ZrnSelectiveSuspend]   driver nvidia, power through zss-kmod, wake on demand: yes
[ZrnSelectiveSuspend]   [1/7] In use by: Xorg (display server, idle), vkcube (application, will be moved)
[ZrnSelectiveSuspend]   [2/7] Applications: 1 moved to 0000:00:02.0, 0 parked
[ZrnSelectiveSuspend]   [3/7] Services stopped: nvidia-persistenced; processes frozen: none
[ZrnSelectiveSuspend]         Hidden from new programs (17): /dev/nvidia0, /dev/dri/card2, ...
[ZrnSelectiveSuspend]   [4/7] PCI state: saved and restored in the kernel (zss module)
[ZrnSelectiveSuspend]   [5/7] Driver nvidia suspended (0.13 s)
[ZrnSelectiveSuspend]   [6/7] Power cut through zss-kmod (0.03 s); the device has left the bus
[ZrnSelectiveSuspend]   [7/7] Watching for wake requests
[ZrnSelectiveSuspend] Device 0000:01:00.0 is powered off (0.43 s).

A card you switch off stays off

• Programs you start meanwhile don't see it, as if it had been unplugged. Vulkan and OpenGL programs run on the other GPU, and nvidia-smi says it can't reach the device.
• If the display server needs the card for a moment, it gets it, and the card switches off again a second or two later. zssctl status counts these as served=.
• If the card has started driving a display by then, it stays on.
• hide_while_off = no in the settings turns hiding off. A program that then reaches the driver waits until zssctl on; zssctl status shows it as waiting=.

A card switched off by the idle timer is different: it isn't hidden, and it comes back for anyone who asks.

Is it really off?

lspci keeps listing the card, because the kernel keeps its entry for a card that can't be removed. Ask the card itself:

lspci -x -s 01:00.0 | head -3     # all "ff": no power. Real bytes: it is on

Programs that can't be moved

A program that uses the card but wasn't started under ZSS_AirLock (a monitor such as btop, say) can't be moved. zssctl off freezes it and zssctl on lets it carry on; the report names it.

• Never frozen: PID 1, systemd-logind, elogind, seatd, the recognised display servers, and the terminal running zssctl off. Your login manager is not on that list.
• zssctl off --console shows the report on a text console and keeps the screen there while the card is off. Press a key to power it on.

Switching off when idle

Set idle_timeout (seconds) in /etc/zss/zssd.conf. A card that drives a display is never powered off, and the timer never freezes anything: a program outside ZSS_AirLock keeps the card on.

A monitor plugged in while the card is off isn't noticed until something asks about displays or you run zssctl on.

zssctl detach 0000:01:00.0                  # move every program off this GPU
zssctl detach 0000:01:00.0 --to 0000:00:02.0  # ... to a chosen GPU
zssctl detach 0000:01:00.0 --to software    # ... to the CPU renderer (if allowed)
zssctl attach 0000:01:00.0                  # bring back every program that started there
zssctl resume PID                           # resume a parked program on a suitable GPU
zssctl monitor                              # follow the daemon's events

A parked program keeps its state while it waits. It is only resumed on the CPU renderer if allow_software = yes.

Trying it without the service

A private daemon with the dry-run backend really moves programs between GPUs but never touches the card's power or driver. This is how the moving tests run.

# terminal 1
zssd --socket "$XDG_RUNTIME_DIR/zss.sock" --gpu 0000:01:00.0=dry-run --allow-software
# terminal 2
export ZSS_SOCKET="$XDG_RUNTIME_DIR/zss.sock"
zss-run vkcube &
zssctl detach 0000:01:00.0
zssctl attach 0000:01:00.0

zss-power-event battery     # switch the dedicated GPU off, moving its programs
zss-power-event ac          # switch it back on and return them
zss-power-event battery --dry-run   # show the progress dialog, switch nothing

• Progress (“Moving application 2 of 3”) appears in zrn-warning-dialog when that is installed.
• ac only switches the card back on if it was the battery event that switched it off. A card switched off by hand stays off.
• The performance manager zrn_perfd calls it on every charger change once it is installed at /usr/local/sbin/zss-power-event. Any other power manager can call it the same way.
• While programs are being moved, the daemon creates /run/zss/moving. A power manager that pauses background programs should leave them running while that file exists: a paused program can't answer the request to move.

ZSS does the host's side. It moves programs off the card, gives the card to vfio-pci, and leaves it alone while a guest has it. On the way back it resets the card with a power cycle and returns it to the host's driver, with its programs.

zssctl lend --check 0000:01:00.0     # what stands in the way, and what would be affected; changes nothing
zssctl lend 0000:01:00.0             # programs moved away, card handed to vfio-pci
zssctl status                        # state=lent, and the process holding the card
zssctl reclaim 0000:01:00.0          # power cycle, host driver back, programs returned
zssctl reclaim 0000:01:00.0 --stay   # the same, leaving programs where they are

zssctl lend --check checks everything under Needs above at once and says, for each obstacle, what would remove it. --json gives the same as one document. sh zss-installer.run --vm-passthrough adds the udev rule that keeps X and the login manager off the card's display nodes (they open every display node of their seat at start-up, even for a card they don't use).

Shared isolation groups

--with-group hands over the other devices in the card's isolation group with it. They have no host driver while the card is lent, and get it back on reclaim. On the reference laptop that is the Thunderbolt controller, so there's no Thunderbolt on the host while the card is lent. Without the option, such a device is an obstacle.

What lending does

1. Moves every program under ZSS_AirLock off the card. A program that has the card open and wasn't started under ZSS blocks the lend: freezing it wouldn't help, because it would still hold the card.
2. Unloads the kernel modules stacked on the card's driver (for NVIDIA: nvidia_uvm, nvidia_drm, nvidia_modeset). It waits up to ten seconds for their users to go, then requires the driver to have no users left. A driver told to let go of a card still in use waits forever, so instead the lend is refused and undone.
3. Unbinds the card's functions from their drivers, with a 15-second limit so that a stuck driver can't take the daemon with it, and binds them to vfio-pci.
4. Marks the card lent. ZSS no longer watches, wakes or powers it, and refuses off, on, detach and attach for it.

Reclaim is refused while a virtual machine holds the card; ZSS never stops a virtual machine. A card that is off is switched on first: zssctl on PCI --stay, then zssctl lend PCI.

Starting a guest

Once the card is lent, any passthrough setup works. With QEMU, for a card whose functions are 01:00.0 and 01:00.1:

qemu-system-x86_64 -machine q35,accel=kvm -cpu host -m 4G \
  -drive if=pflash,format=raw,readonly=on,file=/usr/share/edk2-ovmf/x64/OVMF_CODE.4m.fd \
  -device vfio-pci,host=01:00.0,multifunction=on -device vfio-pci,host=01:00.1 \
  -display gtk ...

With libvirt, add the two functions as host devices with managed='no': ZSS has already bound them, and libvirt mustn't rebind them itself.

On the reference laptop

• IOMMU. A boot entry of its own adds intel_iommu=on iommu=pt. It isn't the default; it's chosen at the boot menu.
• X server. The NVIDIA card is out of the X configuration altogether, and the udev rule puts its display nodes on a seat of their own. Frames drawn on it reach the screen through ZSS_AirLock's presenter. The cost: no PRIME offload through X, and nothing on the outputs wired to the NVIDIA card (the external port) for now.
• Interrupts. The firmware's interrupt-remapping table is broken (“ioapic 2 has no mapping iommu”), so vfio refuses a group until told to allow unsafe interrupts. For one run: echo Y | sudo tee /sys/module/vfio_iommu_type1/parameters/allow_unsafe_interrupts, and N afterwards. This is acceptable for a guest you trust, not for one you don't.
• Display. Arch's qemu-base has no window; install qemu-ui-gtk for -display gtk. The “Mac Edition” card has no option ROM, so QEMU warns and the guest's boot display is QEMU's emulated card.
• Result, 9 October 2026: lent in 2.9 s, used by a QEMU guest running a CachyOS live image, reclaimed in 11.2 s after the guest shut down, with the desktop and its programs running throughout.

Not done yet

• Lending a card straight from “off”.
• Taking the card back automatically when the virtual machine exits (a libvirt hook could call zssctl reclaim).
• Charger events while lent: the power-off they ask for is refused, so the card simply stays lent.

A card that stops answering, or leaves the bus unexpectedly, is noticed by ZSS_Interceptor within about a tenth of a second. It is marked disconnected, and its driver is told through the kernel's PCI error-recovery handlers if it has them, or frozen if it is the patched NVIDIA driver. What follows depends on whether the driver noticed before ZSS did. Here is what happened in real power cuts on the reference laptop, with the card out of X:

zssctl status                 # state=lost
zssctl on 0000:01:00.0        # resumes a frozen driver, or replugs the card the driver gave up

How a card the driver gave up comes back

A program that is rendering calls into the driver many times in the tenth of a second it takes to notice the loss, so the driver usually finds out first (Xid 79 … GPU has fallen off the bus). From then on NVIDIA's driver won't use the card again, and every ordinary way of taking it off the card waits forever: unbinding it, or unloading the modules stacked on it.

NVIDIA's driver does allow one device to leave with programs still holding it: an eGPU pulled from its Thunderbolt port. Patch revision 6 lets ZSS mark the lost card that way. zssctl on then:

1. marks the card as unplugged (/proc/driver/nvidia/zss_hold);
2. takes its functions off the PCI bus while its power is still off, each step with a time limit, so the driver lets go;
3. switches the power rail on and rescans the bridge above the card;
4. waits for nvidia to find the card as a new device, and manages it again.

Tried twice on 9 October 2026 with vkcube rendering and btop polling the card: X answered throughout, vkcube moved to Intel with its picture intact, and afterwards nvidia-smi answered and a new program rendered on the card. The card comes back as /dev/nvidia1; the old device number is freed when its last holder closes it.

The loss_while_busy setting

When the card is idle the driver is frozen if ZSS gets there first, and then it simply resumes. Programs under ZSS_AirLock on a lost card are rebuilt on another GPU from what ZSS_AirLock kept in memory (see ZSS_RETAIN), or parked.

curl -fsSLO https://github.com/z3r0n3br4instorm/ZrnSelectiveSuspend/releases/latest/download/zss-tester.run && sh zss-tester.run

With PySide6 or PyQt6 installed and a desktop running, it opens a window. Otherwise it runs in the terminal (--mail opens your mail program at the end). It takes a few minutes, and does three things:

1. Collects facts: the graphics cards and their drivers, how their power can be switched, the IOMMU, what Vulkan and OpenGL see, the display server, and graphics-related kernel messages.
2. Runs the moving tests: test programs are moved between your graphics cards and back, and what they draw is compared. It uses a test daemon in dry-run mode.
3. Saves the report as a folder and a .tar.gz file in your home folder.

It changes nothing, installs nothing and sends nothing by itself. Before anything is saved, your computer's name, your user name and home folder, disk identifiers, serial numbers, network addresses and email addresses are replaced by placeholders.

Send report opens your mail program addressed to the author with a summary filled in. Attach the .tar.gz (its path is copied for you) and send.

The full test (optional)

It builds and installs ZSS with its kernel module (your graphics driver isn't patched), runs the whole test suite, and switches your discrete card off and on once. It asks for your password and shows every command first.

It builds from source, so it is offered when the kit runs from a checkout of the repository rather than from the download:

git clone https://github.com/z3r0n3br4instorm/ZrnSelectiveSuspend
cd ZrnSelectiveSuspend
tester/zss-report-gui                # or tester/zss-report --full-test in a terminal
sudo ./packaging/uninstall.sh        # removes it again afterwards

The original design put everything in the kernel and shielded a running driver from a vanishing card by shadowing its registers. What was built instead moves programs off the card first, then powers it off with the driver's own cooperation. That needs far less from the kernel, and it works on real hardware today.

A program started under ZSS_AirLock gets it as its only Vulkan driver. ZSS_AirLock loads the real drivers itself and hands out handles of its own. Because it stands between the program and the GPU for every call, it can take a program's work off one GPU and put it on another without the program noticing.

What it keeps

• Every object the program creates: devices, buffers, images, pipelines, descriptor sets, swapchains. Each is a handle of ZSS_AirLock's own, backed by an object on the real GPU that can be replaced.
• Command buffers, recorded in its own form and replayed onto the real GPU, so they can be replayed again on another one.
• Memory the CPU can see, shadowed, so its contents survive a move.
• Uploaded textures, kept on disk (or in RAM) so that a program can be rebuilt even after its GPU vanished without warning (ZSS_RETAIN).

A move, step by step

1. The daemon asks the program, over its control socket, to move off a GPU.
2. ZSS_AirLock holds the program's calls at the door, waits for the GPU to finish, and reads back what lives only on the GPU: images, buffers, the window's current picture.
3. It creates each object again on the new GPU, uploads the contents, and replays the recorded command buffers.
4. It rebuilds the window's swapchain in place, keeping its images' contents, so that a program which redraws only what changed (Chromium does) still shows the whole picture.
5. It lets the program's calls through again. The program never received an error; it just carries on, on another GPU.

The portable profile

A program is offered Vulkan 1.1 with the features and limits that every GPU it might move to has, including the number of queues. Nothing it enables can then hold it to one card. ZSS_PROFILE=native switches this off.

Standing in for missing features

Some extensions are offered on every GPU and emulated where a driver lacks them. Dynamic rendering is lowered to cached render passes and framebuffers. VK_KHR_maintenance5 is mapped onto older calls. That is what lets Zink, and so OpenGL, run on the NVIDIA 470 driver. Also offered: timeline semaphores, extended dynamic state, robustness2, conditional rendering, custom border colours, line rasterisation, transform feedback, sampler Y′CbCr conversion and more.

What it costs

The same programs measured with and without ZSS_AirLock on the reference laptop, frames per second, median of three:

Two costs were found and removed on 9 October. Frames from the NVIDIA card were held to the refresh rate whatever a program asked for; the presenter now uses the program's own present mode. And every submission copied all of a program's mapped memory to the GPU, about 5 GB a second for glxgears; now the kernel reports which pages were written (userfaultfd write protection with PAGEMAP_SCAN, Linux 6.7 and later) and only those are copied.

Presenting on the screen's GPU

A program may draw on one GPU while another drives the screen. Mesa's drivers hand frames across in order themselves. The NVIDIA proprietary driver only does that when the X server has its card. Without that, ZSS_AirLock does it:

• It gives the program ordinary images on its own GPU.
• It keeps the window's real swapchain on a small device of its own on the screen's GPU.
• At each present it reads the frame back, waits for it, copies it in, and presents it there, in order.

This is what fixed text that flickered back to the previous frame while typing in Chromium-based apps. Moves switch between this and direct presenting. ZSS_PRESENT=direct turns it off; copy forces it on.

Housekeeping

• Frames for a swapchain the program has already replaced are dropped instead of presented. This stops a hang on NVIDIA when Zink changes the swap interval.
• When a real driver is closed, ZSS_AirLock closes the render node that NVIDIA's driver leaks, so that a moved program doesn't keep the card busy.
• ZSS_AirLock is linked so that it can't be unloaded, because Chromium unloads its Vulkan driver between probes.

Switching off, in seven steps

1. Who holds the card. Every process with one of the card's device nodes open is found and classed: display server, program under ZSS_AirLock, guest, system process, other.
2. Move. Each program under ZSS_AirLock is asked to move to another GPU (default_target, or the best one available). One that can't go anywhere is parked.
3. Stop and freeze. Services listed in stop_services are stopped; other processes still holding the card are frozen, except PID 1, logind, elogind, seatd, recognised display servers and the terminal running zssctl. The card's device nodes are hidden from new programs.
4. PCI state is saved, in the kernel if ZSS_Interceptor is loaded.
5. Driver suspended through its own sleep code.
6. Power cut through the backend: the gmux on the reference laptop.
7. Watching for wake requests: a display-server call is served by powering the card for a moment.

Switching on runs the same steps backwards, and returns each program to the GPU it started on unless --stay is given.

Rules it keeps

• A card driving a display isn't switched off by the timer.
• PID 1, logind, elogind and seatd are never frozen: they hold the session's device nodes on its behalf.
• While programs are moving it writes /run/zss/moving, so that power managers don't pause them mid-move.
• Lending is refused, rather than risked, whenever the driver couldn't let go cleanly.
• Its state survives a restart: a lent card is still known as lent.

Who may ask

zssctl talks to the daemon over a Unix socket (/run/zss/zssd.sock). Moving, switching and lending are allowed for root, members of the zss group, and the user the daemon runs as. Status is open to everyone. The wire protocol is in docs/protocol.md in the repository.

Loaded, it does nothing until the daemon hands it a device. The daemon drives it through one file per device:

/sys/kernel/zss/0000:01:00.0/power     # off · on · lend · unlend · reclaim

It is built through DKMS and loaded when zssd starts, never from the initial ramdisk. rmmod zss, with the daemon stopped, takes it out. Without it, the daemon does a narrower version of the same from user space (NVIDIA and gmux only), and lending isn't available.

NVIDIA's driver isn't built to have its card switched off under a running display server. The patch adds two things:

• Wake on touch. A caller arriving while the driver is suspended asks for a wake and sleeps, instead of spinning forever. That is how the display server can borrow a switched-off card for a moment.
• Freeze. The driver can be shut to every caller without anything being asked of the card, for the moment a card vanishes, and resumed when the card is back. Revision 5 can also turn callers away at once instead of making them wait (loss_while_busy = refuse).
• Unplugged. Revision 6: a card whose driver saw it vanish can be marked the way the driver marks an eGPU pulled from its port, so that it can be taken off the bus with programs still holding it and found again by a rescan. That is what brings a card lost mid-frame back without a reboot.

zss-nvidia-patch status     # driver version, whether it's validated, whether the patch is in
zss-nvidia-patch apply
zss-nvidia-patch remove     # put the stock driver back

• Validated against 470.256.02 so far (revision 6). The installer offers it only for a validated version.
• It is applied through DKMS on your machine, to the copy of the driver you installed, so it follows kernel updates. A pacman hook re-applies it after a driver update.
• The stock modules are kept, and restored at boot if the patched driver doesn't load.
• ZSS doesn't ship or modify NVIDIA's driver itself. The lines the patch adds are under the MIT licence so that they can be built into NVIDIA's driver.

zssctl status also shows counters: wakes (times woken by a request), served and serving (powered briefly for the display server), waiting (programs asleep on the driver), driver_frozen, iommu, and the seconds left on the idle timer.

Every setting can also be given on the daemon's command line as --name-with-dashes.

git clone https://github.com/z3r0n3br4instorm/ZrnSelectiveSuspend
cd ZrnSelectiveSuspend
meson setup build && ninja -C build
meson test -C build                 # host and QEMU tests: nothing on this machine is powered off
./packaging/install.sh --check      # what this machine supports; changes nothing
sudo ./packaging/install.sh         # install

On Arch the build needs base-devel meson ninja python glslang vulkan-icd-loader libxcb libx11 wayland libglvnd, plus linux-headers for the kernel module. packaging/make-bundle.sh VERSION DIR makes the same .run files as a release.

Where things are

zssctl can't reach zssd

sudo systemctl restart zssd, then journalctl -u zssd -b if it still fails. Programs started before the restart don't register with the new daemon; restart them to make them movable again.

A program started from a terminal isn't moved

Only programs started under ZSS_AirLock can be moved. Start it with zss-run (or zss-run --gl for OpenGL), or turn on ZrnLaunchRouter so that everything you start is routed.

zssctl off says a program still has the device open

That program uses the card but wasn't started under ZSS. Either it is frozen (and named in the report), or, for lending, it blocks the operation. Close it, or start it again with zss-run.

The terminal itself uses the card

The command refuses rather than freeze the terminal you typed into. Run it from a terminal that isn't on the card, or from a text console.

A program doesn't start under zss-run

It probably needs Vulkan 1.2 or later. Run ZSS_DEBUG=1 zss-run … to see why; ZSS_TRAP=1 names a Vulkan command it called that ZSS_AirLock doesn't provide. Run it without zss-run meanwhile.

A program fails to move to the integrated GPU

Usually memory: the target has less, and a game that fills the discrete card can't fit. The program is parked or keeps running where it was; the report says which.

A Chromium or Electron app draws on the CPU

It is missing the two Vulkan switches. zss-run --print app shows whether they are added. Without them it draws through OpenGL and isn't movable.

Text flickers back a frame while typing

Frames from the discrete card weren't reaching the screen in order. ZSS_AirLock now presents through the screen's GPU where needed. If you set ZSS_PRESENT=direct, remove it.

Lending is refused: modules still in use

Something still uses nvidia_drm or its neighbours, often the display server or login manager. Install with --vm-passthrough and reboot, so that they stay off the card's display nodes.

QEMU refuses the group (“no interrupt remapping”)

The firmware's interrupt-remapping table is broken. Allow unsafe interrupts for that run only: see On the reference laptop.

The card was lost while a game was running

zssctl status shows state=lost, and the card's device files are hidden. Run zssctl on: the card is replugged and found again (patch revision 6). The game keeps running on the Intel GPU; restart it to use the card again. A program that draws through NVIDIA's own driver rather than ZSS_AirLock needs a reboot.

Something went wrong during installation

The installer saved a report in ~/.zss/ and offered to send it. ~/.zss/debug.log holds the facts and the installer's own messages either way.

Where to look

zssctl status                   # the daemon's view
journalctl -u zssd -b           # the daemon's log
sudo dmesg | grep -E 'zss|NVRM' # ZSS_Interceptor and the driver
ZSS_DEBUG=1 zss-run program     # [ZSS_AirLock] messages on the terminal
zss-nvidia-patch status         # the driver patch

ZrnSelectiveSuspend is Copyright © 2026 Zerone Laboratories, released under the GNU General Public License, version 2 only. Every source file names it in an SPDX-License-Identifier line. It comes with no warranty: it cuts power to hardware and patches a kernel driver, and you use it at your own risk.

• The NVIDIA driver patch: the lines it adds are under the MIT licence, so that they can be built into NVIDIA's driver. The lines of NVIDIA's code it quotes remain NVIDIA's.
• Vulkan-Headers, from Khronos and included in subprojects/, are under their own licences (Apache-2.0 or MIT).
• The hash in src/common/zss_hash.c is MurmurHash3 by Austin Appleby, which is in the public domain.
